| Auxiliary Power | 12 Volts DC |
| Capacity - Fuel Tank | 117 L / 30.9 gal. |
| Engine Type - Diesel (LRC) | Deutz TD2011L4 56 kW 75 hp |
| Axle Oscillation | 0.3 m / 1 ft |
| Drive Speed - 4WD | 5.20 km/h / 3.2 mph |
| Gradeability - 4WD | 45 % |
| Platform Capacity - Restricted | 450 kg / 992.1 lb |
| Platform Capacity - Unrestricted | 230 kg / 507.1 lb |
| Swing | 360 Degrees |
| Swing Type | Continuous |
| Turning Radius - Outside (axles extended) | 5.89 m / 19.3 ft |
| Turning Radius – Outside (axles retracted) | 6.86 m / 22.5 ft |
| Jib - Range of articulation | 130 Degrees |
| Transport Length | 11.46 m / 37.6 ft |
| Ground Clearance | 0.3 m / 1 ft |
| Machine Height | 3.05 m / 10 ft |
| Machine Length | 14.48 m / 47.5 ft |
| Machine Width | 2.49 m / 8.2 ft |
| Overall Width (Axles Extended) | 3.81 m / 12.5 ft |
| Platform Dimension A | 0.91 m / 3 ft |
| Platform Dimension B | 2.44 m / 8 ft |
| Platform Height | 38.30 m / 125.7 ft |
| Tailswing | 0.91 m / 3 ft |
| Tyre size | 445/50D710 Foam-Filled |
Reach Specification
| Working Height | 40.30 m / 132.2 ft |
| Working Outreach | 19.90 m / 65.3 ft |
| Horizontal Jib Rotation | 125 Degrees |
| Horizontal Outreach | 19.25 m / 63.2 ft |
| Platform Height | 38.30 m / 125.7 ft |
| Up and Over Height | 18.44 m / 60.5 ft |
General Specification
| Capacity - Hydraulic Reservoir | 200.63 L / 53 gal. |
| Maximum Ground Bearing Pressue | 7.03 Kg/cm2 |
| Machine Weight (CE & GOST) | 21000 kg / 46297.1 lb |
