• Roof window screen guard
• Boom prop
• Front window screen guard
• Worklights boom (1st section)
• Rotating Beacon
• Air conditioning
• Wide range of hitches, couplers, carriages and tyres
JLG 4017PS
Key Specs
• Engine glow start assist
• Telescope function reconfiguration
• Fuel gauge
• Battery isolator switch
• Hour- and tachometer
• Frame Leveling
| Make and Model | Deutz TCD 3.6 L4 |
| No. of Cylinders | 4 |
| Standard engine gross power | 74.4kW |
| Maximum torque at 1600 RPM | 420Nm |
| Fuel Tank Capacity | 150 L |
| Rated capacity | 4,000 kg |
| Maximum lift height (stabilisers up) | 15.2 m |
| Maximum lift height (stabilisers down) | 17.3 m |
| Capacity at max height (stabilisers up) | 1000 kg |
| Capacity at max. reach (stabilisers down) | 500 kg |
| Frame leveling | 10° |
| Engine | 74.4kW 4 speed |
| Drawbar pull (loaded) | 69.3kN |
| Outside turning radius (over tyres) | 3.92 m |
| Operating weight | 12310 kg |
